Festo VACF-B-B2-1A 8030804 Solenoid Coil AC 24V IP65

Festo VACF-B-B2-1A is a solenoid coil for pneumatic directional control valves. Rated voltage 24 V AC (50/60 Hz). Pick‑up power 3.9 VA, holding power 2.6 VA. Electrical connection Type B to industry standard (11 mm). IP65 protection. Mounting via knurled nut. Designed for valve series VSNC and VUVS.

Applications:

• Solenoid actuation of VSNC and VUVS series pneumatic valves

• Factory automation and assembly lines

• Packaging and material handling equipment

• OEM valve replacement and maintenance

Core Specifications:

• Manufacturer: Festo

• Part number: 8030804

• Rated voltage: 24 V AC, 50/60 Hz

• Pick‑up power: 3.9 VA

• Holding power: 2.6 VA

• Duty cycle: 100%

• Electrical connection: Type B (industry standard, 11 mm)

• Degree of protection: IP65 (with mating plug)

• Ambient / media temperature: -20 … +50 °C

• Housing material: PA, steel

• Solenoid coil material: Copper, steel, thermoplastic

• Winding material: Copper

Advanced Specifications:

• Insulation class: H

• Mounting position: Any (can be rotated on armature tube)

• Mounting type: Via knurled nut

• Permissible voltage fluctuation: +/- 10 %

• Corrosion resistance class (CRC): 2 – moderate corrosion stress

• Product weight: approx. 55 g

• Approval: c UL us – Recognized (OL)

• Marine classification: DNVGL-TAA000011J (see certificate)

• LABS (PWIS) conformity: VDMA24364‑B1/B2‑L

• RoHS compliant

System Integration:

• Belongs to Festo VACF series of solenoid coils.

• Suitable for valve series VSNC and VUVS.

• Compatible with solenoid armature tube diameter 8 mm.

• For detailed wiring and mounting instructions, refer to the product hardware manual.

Compliance:
Refer to manufacturer official documentation for certification and compliance details.

Related Products:

• VACF-B-B2-1A – 24 V AC, Type B connector (current model)

• VACF-A-A1-1A – 24 V AC, Form A (EN 175301‑803) connector, 2.5 VA

• VACF-B-B2-5 – 12 V DC version

• VACF-B-B2-3W – 230/240 V AC version, 5.8 VA / 4.6 VA
