Festo CPE14-M1CH-5L-1/8 550237 5/2 Solenoid Pilot Valve G1/8 24V DC

Festo CPE14-M1CH-5L-1/8 is a 5/2-way, monostable (single‑solenoid, pneumatic spring return) pilot‑operated solenoid valve from the CPE compact series. With a construction width of just 14 mm and a standard nominal flow rate of 800 L/min, it delivers high flow capacity in a compact body. The valve body is die‑cast aluminium, all pneumatic ports are G1/8 female threads, and the internal pilot air supply simplifies installation. The electrical connection is a 4‑pin M8x1 socket, and when used with a suitable mating plug, the valve achieves IP65 / IP67 protection. The valve is designed for general industrial automation, OEM machinery, and pneumatic control systems requiring reliable directional control of compressed air.

Applications:

• Directional control of double‑acting pneumatic cylinders

• Factory automation and assembly lines

• Packaging and material handling equipment

• OEM machinery and pneumatic control panels

Core Specifications:

• Valve function: 5/2‑way, monostable (single solenoid, pneumatic spring return)

• Actuation type: Electrical pilot operation

• Construction width: 14 mm

• Standard nominal flow rate: 800 l/min (DIN 1343)

• Pneumatic connection: G1/8 (female thread, ports 1 … 5)

• Operating pressure: 3 … 8 bar

• Operating voltage: 24 V DC

• Coil characteristics: 24 V DC – 1.28 W

• Permissible voltage fluctuation: –15 … +10 %

• Switching times: Off 32 ms / On 24 ms

• Duty cycle: 100 %

• Protection rating: IP65 / IP67 with mating plug (IEC 60529)

• Electrical connection: 4‑pin M8x1 socket

• Corrosion resistance class (CRC): 2 – moderate corrosion stress

• Dimensions, Weight: 95 g (valve body) / 113 g (packaged)

• Ambient / media temperature: –5 °C … +50 °C

Advanced Specifications:

• Design: Piston gate valve with soft sealing

• Reset method: Pneumatic spring

• Pilot air supply: Internal; pilot ports M3

• Exhaust air function: with flow control option

• Manual override: Detenting (via accessory) and non‑detenting variants available

• Lap: Overlap

• Max. positive test pulse (0 signal): 1200 µs

• Max. negative test pulse (1 signal): 900 µs

• Nominal width: 6 mm

• Housing material: Die‑cast aluminium

• Seal material: NBR

• Operating medium: Compressed air to ISO 8573‑1:2010 [7:4:4]; lubricated operation possible (if lubricated, continued lubrication required)

• Mounting position: any; mounting type: through‑hole

• Vibration / shock resistance: severity level 2 (FN 942017‑4/‑5, EN 60068‑2‑27)

• RoHS compliant

System Integration:

• This valve belongs to the Festo CPE compact series.

• The valve body is delivered without a mating plug; a suitable 4‑pin M8x1 plug (IP65/IP67) must be selected and ordered separately.

• Manifold mounting is supported via CPE manifold rails (multiple valve positions possible).

• For detailed drawings, pneumatic circuit diagrams, and accessory ordering information, refer to the official Festo CPE series hardware manual.

Standards & Compliance:
Refer to manufacturer official documentation for detailed certification and compliance information.

Related Products:

• CPE14‑M1BH‑5L‑1/8 (196941) – Similar valve, different pilot configuration

• CPE14‑M1CH‑5L‑1/8 (550237) – Current model

• CPE14‑M1BH‑5JS‑1/8 – Variant with different manual override

• M8‑4‑PIN mating plug – 4‑pin M8x1 socket, IP65/IP67 (order separately)
