OGH200 Diffuse Reflection Sensor 250mm PNP M12 | IFM

The Original New IFM OGH200 Diffuse Reflection Sensor with Background Suppression is a robust photoelectric sensor designed for reliable object detection in harsh industrial environments. Featuring precise geometric background suppression, this sensor reliably detects objects regardless of colour while ignoring background interference. The M18 threaded stainless steel housing, intuitive potentiometer adjustment, and red light sensing make it ideal for factory automation, material handling, and machine control applications.

Core Engineering Highlights:
15–250mm detection range | PNP light‑on output | Red light (624nm) | 10–36V DC operating voltage | 200mA output current | 1kHz switching frequency | M18 x 1 threaded stainless steel housing | IP65 protection | –25°C to +60°C operating temperature | M12 connector

Key Features:

• Original New IFM OGH200 sensor

• Diffuse reflection sensing principle with precise geometric background suppression

• Detection range: 15–250mm (white object, 90% remission)

• Reliable detection of black objects up to 160mm and grey objects up to 230mm

• Red light source (624nm wavelength) for easy alignment

• PNP output with light‑on mode

• 200mA output current capacity with short‑circuit and overload protection

• 1kHz switching frequency for high‑speed applications

• Intuitive sensitivity adjustment via potentiometer

• Robust stainless steel (V4A) housing for harsh environments

• IP65 protection rating for dust‑tight and water‑resistant operation

• M18 x 1 threaded barrel with 72mm length

• M12 connector (A‑coding) for quick electrical connection

• Yellow LED switching status indicator

• 2 lock nuts included in delivery

• MTTF: 339 years

• cULus - Class 2 source required

Applications:

• Object detection on conveyor and material handling systems

• Positioning and presence monitoring in automated assembly lines

• Packaging machinery and OEM equipment

• Part counting and quality inspection

• Factory automation requiring background suppression

• High-vibration environments requiring stainless steel housing

Technical Specifications:

Detection Range:

• White Object (90% remission): 15–250 mm

• Grey Object (18% remission): 15–230 mm

• Black Object (6% remission): 15–160 mm

• Range Adjustable: Yes

• Max. Light Spot Diameter: 21 mm

Electrical Data:

Outputs:

Environmental & Mechanical:

System Compatibility:

• PLCs via PNP digital input

• M12 A‑coded connection cables (3‑wire)

• Industrial control systems requiring background suppression

• 24V DC power supplies (Class 2 source required)

• IFM mounting brackets and accessories

Adjustment Instructions:

1. Set the potentiometer to the smallest sensing range

2. Place the object to be detected within the sensing range

3. Increase the sensing range until the LED lights (minimum value; object detected)
