ACS580-01-206A-4 110kW General Purpose Drive 400V IP21 R7 | ABB

The Original New ABB ACS580-01-206A-4 is a 110 kW (150 HP) general purpose wall-mounted drive from the ABB ACS580 series, engineered for reliable high-power motor control across a wide range of demanding industrial applications. Rated at 206 A with a 380–480 V three-phase input, this drive delivers efficient speed and torque control for compressors, conveyors, pumps, extruders, centrifuges, mixers, fans, and many other variable and constant torque applications. Featuring an IP21 / UL Type 1 enclosure, integrated EMC filter (Category C2), built-in brake chopper, and Safe Torque Off (STO) safety function, the ACS580-01-206A-4 simplifies installation and reduces the need for external components. The drive is part of the all-compatible ABB general purpose drive portfolio, and includes an intuitive assistant control panel for fast commissioning. Its robust R7 frame design makes it suitable for heavy industrial environments across multiple sectors, including food and beverage, mining, water treatment, material handling, and oil and gas.

Core Engineering Highlights:
110 kW (150 HP) Normal Duty power rating | 206 A nominal output current (Normal Use) | 196 A Light‑Overload use | 169 A Heavy‑Duty use | 90 kW Heavy Duty output power | 380–480 V 3‑phase input | 0–500 Hz output frequency range | IP21 / UL Type 1 wall‑mounted enclosure | Frame size R7 | Integrated EMC filter (Category C2) + built‑in brake chopper | Safe Torque Off (STO) SIL3 / PLe safety function | Assistant control panel with USB connectivity | Modbus RTU via RS‑485 standard | IE2 efficiency level | 2346 W power dissipation | 67 dB sound level

Key Features:

• Original New ABB ACS580-01-206A-4 drive (3ABD00045439-D)

• 110 kW (150 HP) rated output power (Normal Duty / Light‑Overload)

• Heavy Duty output: 90 kW

• 206 A nominal output current (Normal Use)

• 196 A Light‑Overload output current / 169 A Heavy‑Duty output current

• 380–480 V AC 3‑phase input, 47.5–63 Hz

• 0–500 Hz output frequency range

• IP21 / UL Type 1 enclosure for control cabinet or wall mounting

• Frame size R7 with robust construction

• Integrated EMC filter (Category C2) and built‑in brake chopper

• Safe Torque Off (STO) safety function — SIL3 / PLe as standard

• Assistant control panel included with USB connectivity for easy commissioning

• Built‑in energy optimizer for improved efficiency

• Scalar (V/f) and sensorless vector control modes

• Modbus RTU communication via RS‑485 standard

• Heavy‑duty overload capacity: 150% for 60 seconds

• PID control for closed‑loop applications

• 6 digital inputs, 3 relay outputs, 2 analog inputs, 2 analog outputs

• Coated boards for environmental protection

• Wall‑mounted design for simple installation

Applications:

• Compressors and compressed air systems

• Conveyors and material handling systems

• Pumps and water/wastewater treatment systems

• Fans, blowers and ventilation equipment

• Extruders, centrifuges and mixers

• Food and beverage production facilities

• Mining and mineral processing

• Oil and gas, chemical and petrochemical facilities

• General industrial automation and heavy machinery

Technical Specifications:

System Compatibility:

• Compatible with a wide range of industrial communication protocols including Modbus RTU (built‑in), CAN, DeviceNet, EtherNet/IP, PROFIBUS, PROFINET IO, and TCP/IP via optional fieldbus adapters

• USB connectivity for PC connection and drive configuration

• Compatible with ABB ACS580 series accessories including control panels (ACS‑CP‑C, ACS‑CP‑D, ACS‑AP‑I), mounting kits, and communication adapters

• Suitable for use with ABB motors and third‑party motors

• Supports PID control for closed‑loop applications

Related Products:

• ACS‑CP‑C – Basic control panel with numeric display

• ACS‑CP‑D – Basic control panel with multi‑language support

• ACS‑AP‑I – Advanced control panel with graphical display

• ACS580‑01‑169A‑4 – 90 kW version (lower power)

• ACS580‑01‑206A‑4 – 110 kW version (current model)

• ACS580‑01‑246A‑4 – 132 kW version (higher power)

• Fieldbus adapters – PROFIBUS, PROFINET, EtherNet/IP, DeviceNet

• Mounting kit – For panel or remote mounting of control panel

• Braking resistors – For external dynamic braking applications

• UL Type 12 hood – Optional accessory for enhanced environmental protection

PLC ERA is an independent industrial automation distributor supplying genuine Original New products through established global supply channels. All products are factory sealed when applicable and undergo quality inspection prior to shipment. ABB is a trademark of ABB Group.
