Allen‑Bradley 1769-IF16C 16‑Point CompactLogix Analog Current Input Module

Allen‑Bradley 1769‑IF16C is a high‑density analog current input module for CompactLogix systems, designed to accept 0‑20 mA and 4‑20 mA signals from transmitters, sensors, and field instruments in industrial automation.

• Product Code：1769‑IF16C

• Number of Inputs：16 single‑ended (0‑20 mA, 4‑20 mA)

• Input Full‑Scale Ranges：0…21 mA and 3.2…21 mA

• Resolution：16 bits (unipolar), 15 bits plus sign (bipolar)

• Bus Current Draw：190 mA @ 5 V DC, 70 mA @ 24 V DC

• Heat Dissipation：4.0 W max

• Input Impedance：249 Ω

• Accuracy：±0.5 % full scale @ 25 °C

• Isolation Voltage：500 V AC / 710 V DC (group to bus)

• Operating Temperature：0…60 °C

• Mounting：DIN rail or panel mount (1769 chassis)

• Dimensions (W × H × D)：approx. 35 × 118 × 87 mm (1.38 × 4.65 × 3.43 in)

• Weight：approx. 281 g (0.62 lb)

• Certifications：CE, RoHS

Applications:

• Process control monitoring (pressure, flow, level)

• Factory automation signal acquisition from 4‑20 mA transmitters

• Condition monitoring of pumps, motors, and drives

• Machine data collection in manufacturing lines

• Temperature monitoring with analog sensors

System Integration:

• PLC Controllers：CompactLogix 5370 L3, Compact GuardLogix 5370, MicroLogix 1500

• I/O System：1769 Compact I/O family

• Networks：EtherNet/IP (via 1769‑AENTR adapter)

• Software：Studio 5000 / RSLogix 5000

• Terminal Block：Removable (included)

Related Products:

• Controller：1769‑L33ER CompactLogix – system core

• Analog Output Module：1769‑OF8 CompactLogix Analog Output – output pairing

• Digital Input Module：1769‑IQ32 Digital Input – mixed I/O expansion

• EtherNet/IP Adapter：1769‑AENTR – distributed I/O connectivity

PLC ERA is an independent industrial automation distributor. Products are sourced from established supply channels and inspected before shipment. International shipping available.
