25B-D010N104 PowerFlex 525 4kW (5HP) AC Drive | Allen-Bradley

The Original New Allen-Bradley 25B-D010N104 4kW (5HP) AC Drive is a PowerFlex 525 series compact variable frequency drive designed for precise motor speed control in industrial automation systems. Featuring built-in EtherNet/IP™ communication, this drive delivers reliable performance for a wide range of motor control applications, from conveyor systems to complex machine automation. Its modular design with a removable control core enables simultaneous installation and software configuration, reducing downtime and simplifying maintenance. Built-in Safe Torque Off (STO) provides certified safety functionality at PLd/SIL2 Cat 3. Frame B size with IP20 / NEMA Open Type enclosure.

Core Engineering Highlights:
4kW (5HP) output power | 10.5A output current | 380-480V AC 3-phase input | Frame B size | Built-in EtherNet/IP | Safe Torque Off (STO) PLd/SIL2 | IP20/NEMA Open Type | 97.5% typical efficiency | 0-500 Hz output frequency

Key Features:

• Original New Allen-Bradley 25B-D010N104 drive

• 4kW (5HP) output power with 10.5A output current

• 380-480V AC 3-phase input, 50/60Hz

• Built-in EtherNet/IP™ communication port for seamless Logix integration

• Frame B size with compact footprint

• Safe Torque Off (STO) certified at PLd/SIL2 Cat 3

• Integral keypad with potentiometer and LED display for local control

• Built-in brake IGBT for dynamic braking

• Multiple control methods: Volts/Hertz, Sensorless Vector Control, Closed Loop Velocity Vector Control

• Permanent magnet motor control capability

• Removable control core for simultaneous installation and software configuration

• Zero Stacking™ mounting with 50mm airflow gap

• Optional communication protocols: DeviceNet, ProfiBus DP, Dual EtherNet/IP

• IP20 / NEMA Open Type enclosure

• 97.5% typical efficiency

• Output frequency: 0-500 Hz (programmable)

• 4-quadrant operation capable

Applications:

• Conveyor speed control and material handling systems

• Pump and fan control

• Packaging machinery

• Machine tool drives

• OEM equipment and general industrial automation

• Permanent magnet motor applications

• Mixer and compressor applications

Technical Specifications:

• Catalog Number: 25B-D010N104

• Product Family: PowerFlex 525 AC Drive

• Frame Size: Frame B

• Output Power (Normal Duty): 4 kW (5 HP)

• Output Power (Heavy Duty): 4 kW (5 HP)

• Output Current: 10.5 A

• Input Voltage: 380-480V AC, 3-phase

• Input Voltage Range: 323-528V AC

• Input Frequency: 50/60 Hz

• Output Voltage: 0-460V AC, 3-phase

• Output Frequency: 0-500 Hz (programmable)

• Efficiency: 97.5% typical

• Control Methods: Volts/Hertz, Sensorless Vector Control, Closed Loop Velocity Vector Control, PM Motor Control

• Brake IGBT: Included

• Safety: Safe Torque Off (STO) – PLd/SIL2 Cat 3

• User Interface: Integral keypad with potentiometer and LED display

• I/O: 7 Discrete Inputs (Sink/Source), 2 Discrete Outputs, 2 Analog Inputs, 1 Analog Output

• Built-in Communication: EtherNet/IP

• Optional Protocols: DeviceNet, ProfiBus DP, Dual EtherNet/IP

• Enclosure Rating: IP20 / NEMA Open Type

• Operating Temperature (No Derate): -20°C to 50°C

• Operating Temperature (Derate): Up to 70°C

• Dimensions (HxWxD): Approx. 180 x 87 x 172 mm (7.09 x 3.43 x 6.77 in.)

• Weight: Approx. 1.6 kg

• Certifications: CE, UL, cUL, C-Tick, ATEX, KCC, RCM

• UPC: 884951885912

• EAN: 00884951885912

System Compatibility:

• Rockwell Automation Logix controllers (ControlLogix, CompactLogix, GuardLogix)

• EtherNet/IP networks

• Studio 5000 Logix Designer® application

• Connected Components Workbench software

• DeviceNet and ProfiBus DP networks (with optional modules)

Related Products:

• 25B-D010N114 – 4kW (5HP), Frame B, with conformal coating (harsh environments)

• 25B-D013N104 – 5.5kW (7.5HP), Frame C, standard

• 25B-D017N104 – 7.5kW (10HP), Frame C, standard

• 25B-D024N104 – 11kW (15HP), Frame D, standard

• 25-COMM-D – DeviceNet communication module for PowerFlex 525

• 25-COMM-P – ProfiBus DP communication module for PowerFlex 525

• 25-COMM-E2P – Dual-port EtherNet/IP communication module (for DLR support)

PLC ERA is an independent industrial automation distributor supplying 100% genuine Original New products through established global supply channels. Allen-Bradley, PowerFlex, ControlLogix, CompactLogix, and Studio 5000 are trademarks of Rockwell Automation.
