25B-D013N114 PowerFlex 525 5.5kW (7.5HP) AC Drive Frame C | Allen-Bradley

The Original New Allen-Bradley 25B-D013N114 PowerFlex 525 5.5kW (7.5HP) AC Drive is a compact, high-performance variable frequency drive designed for three-phase motor control in industrial automation systems. Featuring built-in EtherNet/IP™ communication, integrated EMC filtering, and Safe Torque Off (STO) safety functionality, this drive delivers reliable motor speed control for a wide range of applications including conveyors, pumps, fans, and mixers.

Core Engineering Highlights:
5.5kW (7.5HP) output power | 13A output current | 380-480V AC 3-phase input | 0-500Hz output frequency | Frame C size | Integrated EMC filter | Built-in EtherNet/IP + RS485 | Safe Torque Off (STO) | IP20 / NEMA Open Type | 97.5% typical efficiency

Key Features:

• Original New Allen-Bradley 25B-D013N114 drive

• 5.5kW (7.5HP) output power with 13A output current

• 380-480V AC 3-phase input, 50-60Hz

• Output frequency: 0-500Hz (programmable)

• Built-in EtherNet/IP™ communication port for seamless Logix integration

• Integrated EMC filter (CE compliant)

• Safe Torque Off (STO) functionality for certified safety

• Built-in brake IGBT for dynamic braking

• Integral keypad with potentiometer and LED display

• Control methods: Volts/Hertz (V/Hz), Sensorless Vector Control (SVC), Closed Loop Velocity Vector Control, Permanent Magnet Motor Control

• Frame C size with compact footprint

• Panel or DIN rail mounting

• Zero Stacking™ support for side-by-side mounting

• USB programming capability for easy configuration

Applications:

• Conveyor speed control and material handling systems

• Pump and fan control with energy-efficient operation

• HVAC systems requiring variable speed control

• Packaging machinery and OEM equipment

• Mixers and industrial process equipment

• General industrial automation and machine control

Technical Specifications:

• Catalog Number: 25B-D013N114

• Product Family: PowerFlex 525 AC Drive

• Frame Size: Frame C

• Output Power: 5.5 kW (7.5 HP)

• Output Current: 13 A

• Output Voltage: 0-460V AC

• Input Voltage: 380-480V AC, 3-phase

• Input Voltage Range: 323-528V AC

• Input Frequency: 50-60 Hz

• Output Frequency: 0-500 Hz (programmable)

• Efficiency: 97.5% (typical)

• Power Factor: 0.98

• Control Methods: Volts/Hertz, Sensorless Vector Control, Closed Loop Velocity Vector Control, Permanent Magnet Motor Control

• Brake IGBT: Included

• EMC Filter: Integrated

• Safety: Safe Torque Off (STO)

• I/O: 7 Discrete Inputs (Sink/Source), 2 Discrete Outputs, 2 Analog Inputs, 1 Analog Output

• Built-in Communication: EtherNet/IP, RS485

• User Interface: Integral keypad with potentiometer and LED display

• Enclosure Rating: IP20 / NEMA Open Type

• Mounting: Panel Mount or DIN Rail

• Zero Stacking: Supported

• Dimensions (HxWxD): 220 x 109 x 184 mm (8.66 x 4.29 x 7.24 in.)

• Weight: Approx. 4.2 kg (9.26 lbs)

• Ambient Temperature (No Derate): –20°C to +50°C

• Ambient Temperature (With Derate): Up to 70°C

• Certifications: CE, UL, cUL, C-Tick

• Country of Origin: China

• UPC: 884951886049

System Compatibility:

• Rockwell Automation Logix controllers (ControlLogix, CompactLogix, GuardLogix)

• EtherNet/IP networks

• Studio 5000 Logix Designer® application

• Connected Components Workbench software

• RS485 serial communication

Typical System Architecture:
1769 / 1756 Power Supply
↓
ControlLogix / CompactLogix Controller
↓
EtherNet/IP Network
↓
25B-D013N114 PowerFlex 525 Drive
↓
Three-Phase Induction or Permanent Magnet Motor

Related Products:

• 25B-D010N114 – 4.0kW (5HP), Frame B

• 25B-D017N114 – 7.5kW (10HP), Frame C

• 25-COMM-D – DeviceNet communication module

• 25-COMM-P – ProfiBus DP communication module

• 25-COMM-E2P – Dual-port EtherNet/IP communication module

• 25B-D013N114K – Conformal coated version for harsh environments

• 1769-L33ER – CompactLogix 5370 controller, 2MB, dual Ethernet with DLR

PLC ERA is an independent industrial automation distributor supplying 100% genuine Original New products through established global supply channels. Allen-Bradley, PowerFlex, ControlLogix, CompactLogix, and Studio 5000 are trademarks of Rockwell Automation.
