5069-RTB64-SCREW Compact 5000 64-Position Screw RTB | Allen-Bradley

The Original New Allen-Bradley 5069-RTB64-SCREW is a 64-position removable terminal block (RTB) kit designed for the Compact 5000 I/O system. It provides the physical interface for field-side wiring to 5069-series I/O modules, using screw-type terminations for secure, reliable electrical connections. The kit includes both the 5069-RTB4-SCREW and 5069-RTB6-SCREW terminal blocks, supporting power and signal connections for up to 31 I/O modules in a single system. Engineered for the high-performance Compact 5069 platform, these RTBs deliver reliable connectivity, proper signal routing, and safe termination in demanding industrial control applications.

Core Engineering Highlights:
64-position screw-type terminal block kit | Includes 4-pin + 6-pin power terminal RTBs | 10A current rating | 300V AC voltage rating | 0.4 N·m (3.5 lb·in) torque specification | 22–12 AWG (0.34–3.3 mm²) wire size | 0°C to +60°C operating temperature | Open-style enclosure | CIP Sync support | Compact 5000 I/O system compatibility

Key Features:

• Original New Allen-Bradley 5069-RTB64-SCREW terminal block kit

• 64-position screw-type termination for high-integrity electrical contact

• Includes 5069-RTB4-SCREW (4-pin) and 5069-RTB6-SCREW (6-pin) terminal blocks

• Screw terminals provide superior clamping force and prevent wire pull-out in high-vibration environments

• Secure locking mechanism maintains electrical continuity under mechanical stress

• Supports up to 31 I/O modules in a single Compact 5069 I/O system

• Open-style enclosure for straightforward installation

• CIP Sync support for precise time synchronization across the control architecture

• Pattern matching functionality for advanced control applications

• Supports solid or stranded copper wire rated at 75°C or greater

• 4 Form C (SPDT) outputs with wide AC/DC signal voltage support

Applications:

• Field wiring interface for Compact 5000 I/O modules (digital, analog, specialty)

• Power and signal connections for CompactLogix 5380 and Compact GuardLogix 5380 systems

• Distributed I/O applications over EtherNet/IP networks

• Industrial control panels requiring modular I/O wiring

• Machine automation and process control systems

• High-vibration environments requiring secure screw terminations

Technical Specifications:

System Compatibility:

• Rockwell Automation Compact 5000 I/O modules (5069 series)

• CompactLogix 5380 controllers

• Compact GuardLogix 5380 controllers

• 5069 Compact I/O EtherNet/IP adapters

• Studio 5000 Logix Designer® application

Typical System Architecture:
CompactLogix 5380 / GuardLogix 5380 Controller
↓
5069 Compact I/O Modules (up to 31 modules)
↓
5069-RTB64-SCREW RTB Kit (field wiring interface)
│
├── 5069-RTB4-SCREW (4-pin power connection)
└── 5069-RTB6-SCREW (6-pin power connection)
↓
Field Devices (Sensors, Actuators, Power Distribution)

Related Products:

• 5069-RTB64-SPRING – 64-position spring-type RTB (alternative termination)

• 5069-RTB18-SCREW – 18-position screw-type RTB for Compact 5000

• 5069-IB16 – 16-point 24V DC digital input module

• 5069-OB16 – 16-point 24V DC digital output module

• 5069-IF8 – 8-channel analog input module

• 5069-OF4 – 4-channel analog output module

• 5069-AEN2TR – EtherNet/IP adapter for Compact 5000 I/O

• 5069-L320ER – CompactLogix 5380 controller, 2MB, dual Ethernet with DLR

PLC ERA is an independent industrial automation distributor supplying 100% genuine Original New products through established global supply channels. Allen-Bradley, CompactLogix, Compact GuardLogix, and Studio 5000 are trademarks of Rockwell Automation.
