AS228T-A AS200 Series Mid-Range PLC 16DI/12DO NPN Ethernet | Delta

The Original New Delta AS228T-A is a 28-point mid-range PLC CPU module from the AS200 series, engineered for high-speed automation across electronics manufacturing, food packaging, labelling, and textile machinery applications. Powered by a 32-bit SoC CPU, it achieves a basic LD instruction execution speed of 25 ns and MOV operations in approximately 0.15 µs. The module provides 16 digital inputs and 12 NPN transistor outputs, with program capacity of 64k steps and data register capacity of approximately 60k words. Featuring a built-in 10/100 Mbps Ethernet port, dual RS-485 ports, CANopen, and Mini USB, the AS228T-A supports Modbus TCP, EtherNet/IP, and Modbus RTU/ASCII communication protocols. Its compact modular design supports up to 32 extension modules for a maximum of 1,024 I/O points, with 6-axis 200 kHz pulse output and 4-channel 200 kHz high-speed counter for motion and positioning control.

Core Engineering Highlights:
16 DI / 12 DO (NPN transistor) | 64k steps program capacity / ~60k words data registers | 25 ns LD / 0.15 µs MOV execution speed | Built-in Ethernet + 2x RS-485 + CANopen + Mini USB | 6-axis 200 kHz pulse output / 4-channel 200 kHz high-speed counter | Max. 1,024 I/O points via 32 extension modules | 24 V DC power supply | 0°C to +55°C operating temperature

Key Features:

• Original New Delta AS228T-A CPU module

• 32-bit SoC CPU for high-speed execution

• 16 digital inputs (24V DC, sink/source)

• 12 NPN transistor outputs

• 64k steps program capacity, ~60k words data registers

• Built-in Ethernet (10/100 Mbps) supporting Modbus TCP and EtherNet/IP

• 2 x RS-485 ports (isolated) for Modbus RTU/ASCII

• 1 x Mini USB programming port

• CANopen built-in, supports up to 8 axes of servo control via CANopen networking

• 6-axis 200 kHz high-speed pulse output for positioning control

• 4-channel 200 kHz high-speed counter input

• Up to 32 extension modules (max. 16 analog modules)

• Maximum 1,024 I/O points

• Micro SD card slot for data logging, backup, and firmware updates

• Real-time clock (RTC) with NTP time sync

• Programmed via Delta ISPSoft (IEC 61131-3: LD, ST, FBD, SFC, IL)

Applications:

• Electronics manufacturing and PCB assembly equipment

• Food and beverage packaging machinery

• Labelling and printing equipment

• Textile and woodworking machinery

• Material handling and conveyor systems

• General factory automation and machine control

• Positioning and motion control applications up to 6 axes

Technical Specifications:

System Compatibility:

• Compatible with Delta AS200 series extension modules (digital, analog, temperature, load cell)

• Supports up to 32 extension modules (max. 16 analog modules)

• Compatible with Delta AS series function cards (AS-FCOPM for CANopen, AS-F2AD/AS-F2DA for analog I/O, AS-F232/AS-F485 for serial communication)

• Programmed with Delta ISPSoft software

• Compatible with Delta HMI, VFD, and servo systems via Modbus or EtherNet/IP

• CANopen support for up to 8 axes of Delta servo control

• Note: EtherCAT communication is not supported on the AS200 series

Related Products:

• AS228P-A – AS200 series CPU, 16DI/12DO (PNP transistor output)

• AS228R-A – AS200 series CPU, 16DI/12DO (relay output)

• AS218TX-A – AS200 series CPU, 8DI/6DO + 2AI/2AO, 3-axis 200 kHz pulse output

• AS320T-B – AS300 series CPU, 8DI/12DO (NPN), higher performance

• AS-PS02 – Power supply module, 100–240 V AC input

• AS-PS02A – Power supply module, 100–240 V AC input

• AS16AN01T-A – 16-point digital output extension module

• AS08AD-B – 8-channel analog input extension module

• AS-FCOPM – CANopen communication function card
