ASD-A2-2023-M 2kW AC Servo Drive 220V 3-Phase 13.4A | Delta

The Original New Delta ASD-A2-2023-M is a 2 kW AC servo drive from the ASDA-A2 series, designed for high-precision motion control in industrial automation. Rated at 2 kW with a 220 V AC three-phase input and 13.4 A continuous output current, it delivers reliable position, speed, and torque control for demanding machine applications. The drive supports pulse input, analog voltage control, full-closed loop control, PR parameter mode, and electronic cam (E-CAM) functions. Built-in CANopen and RS-485 communication enable integration into networked motion control systems. The ASD-A2-2023-M is a field-replaceable drive for machines using Delta ECMA series 2 kW servo motors.

⚠️ Important Product Status Note:

This product has been discontinued by Delta Electronics and is no longer in production. The recommended replacement is the ASD-B3A-2023-L (ASDA-B3 series, 2 kW, 220 V, 13.4 A). The ASDA-B3 series offers a 24-bit absolute encoder, 3.1 kHz frequency response, and 3.5× torque overload. For new designs, please consider the replacement model. The ASD-A2-2023-M remains available for maintaining existing ASDA-A2 installations while supplies last.

Core Engineering Highlights:
2 kW rated output power | 13.4 Arms continuous output current / 40.20 Arms peak | 220 V AC 1/3-phase input | 20-bit encoder resolution (1,280,000 ppr) | CANopen + RS-485 communication | Pulse input up to 4 Mpps (line driver) | 0°C to +55°C operating temperature | Supports position, speed, and torque control modes

Key Features:

• Original New Delta ASD-A2-2023-M servo drive

• 2 kW rated output power with 13.4 Arms continuous output current

• 40.20 Arms instantaneous maximum output current

• 220 V AC input (single-phase or three-phase)

• 20-bit encoder resolution (1,280,000 pulses/revolution)

• Supports position, speed, and torque control modes

• Pulse input frequency: 200 Kpps (open collector) / 500 Kpps / 4 Mpps (line driver)

• Built-in CANopen (DS301, DS402) and RS-485 (Modbus) communication

• Analog voltage control and PR parameter mode support

• Full-closed loop control capability

• Electronic cam (E-CAM) function with up to 720 E-CAM points

• Built-in automatic low-frequency vibration suppression

• 64 programmable positions in PR mode

• 35 HOME modes available

• Programmed via ASDA-A2-Soft configuration software

Applications:

• CNC machine tools and precision machining

• Pick-and-place and assembly automation

• Packaging machinery and labeling equipment

• Semiconductor manufacturing equipment

• Robotics and material handling systems

• Printing and textile machinery

• Machine tools requiring high-precision positioning

Technical Specifications:

System Compatibility:

• Compatible with Delta ECMA series 2 kW servo motors: ECMA-C11020□S (S=22 mm), ECMA-E11320□S (S=22 mm), ECMA-E11820□S (S=35 mm)

• Drive model and motor compatibility should be verified before installation

• Programmed via ASDA-A2-Soft configuration software

• Compatible with Delta motion controllers and PLCs via CANopen or RS-485

Related Products:

• ASD-B3A-2023-L – ASDA-B3 series 2 kW servo drive (recommended replacement)

• ASD-A2-1521-M – 1.5 kW version (lower power)

• ASD-A2-3023-M – 3 kW version (higher power)

• ECMA-C11020□S – 2 kW low-inertia servo motor (22 mm shaft)

• ECMA-E11320□S – 2 kW medium-inertia servo motor (22 mm shaft)

• ECMA-E11820□S – 2 kW medium-inertia servo motor (35 mm shaft)

• ASD-BM-50A – DIN rail I/O extension kit

• ASD-IF-SC5020 – Front connector (press-fit)

• ASD-CNIE0B06 – RS-485 communication connector
