ASD-B2-1521-B 1.5kW AC Servo Drive 220V 1/3 Phase | Delta

The Original New Delta ASD-B2-1521-B is a 1.5 kW AC servo drive from the ASDA-B2 series, designed for high-precision positioning control in general-purpose machine tool and industrial automation applications. Rated 1.5 kW (2 HP) with 8.3 Arms continuous output current and 24.90 Arms instant maximum output current, it operates on 220 V AC single-phase or three-phase input. The drive supports position, speed, and torque control modes, with a maximum pulse input frequency of 4 Mpps for high-precision positioning. Equipped with RS-232 and RS-485 communication interfaces, the ASD-B2-1521-B enables flexible integration into automation systems. It is compatible with Delta ECMA series servo motors, particularly the ECMA-E21315RS for 1.5 kW applications.

Core Engineering Highlights:
1.5 kW (2 HP) rated output power | 8.3 Arms continuous output current / 24.90 Arms instant max current | 220 V AC, 1-phase or 3-phase input | Position, Speed, and Torque control modes | 4 Mpps max pulse input frequency | 20-bit or 17-bit encoder support | RS-232 + RS-485 communication | 0°C to +55°C operating temperature

Key Features:

• Original New Delta ASD-B2-1521-B servo drive

• 1.5 kW (2 HP) rated output power with 8.3 Arms continuous output current

• 24.90 Arms instant maximum output current for dynamic load handling

• Supports 220 V AC single-phase or three-phase input

• Three control modes: Built-in position, speed, and torque (speed and torque controlled by internal parameters or analog voltage)

• High-speed differential command input up to 4 Mpps for high-precision positioning

• Supports 20-bit and 17-bit encoders for high-precision positioning control and stable low-speed operation

• Built-in motion control functions for general-purpose applications

• RS-232 and RS-485 communication interfaces for system integration

• Separated power supply for main circuit and control circuit for easier maintenance

• Easy-to-use digital keypad for parameter setting and real-time monitoring

• ASDA-Soft configuration software for fast tuning and setup

• Compact chassis-mount design for control cabinet installation

Applications:

• General-purpose machine tools

• CNC machine tools and milling heads

• Industrial robotic arms and manipulators

• Packaging machinery

• Textile and woodworking equipment

• Precision positioning systems

• Automated production lines

• Material handling systems

Technical Specifications:

System Compatibility:

• Compatible with Delta ECMA series AC servo motors, including ECMA-E21315RS (1.5 kW), ECMA-E21315SS (with brake), and other 1.5 kW ECMA motors

• Supports Delta ASDA-Soft configuration software for tuning and parameter management

• Compatible with Delta DVP, AS, AH series PLCs for motion control integration

• Supports pulse train command from PLC positioning modules and motion controllers

Related Products:

• ECMA-E21315RS – 1.5 kW AC servo motor (recommended matching motor)

• ECMA-E21315SS – 1.5 kW AC servo motor with brake

• ASD-B2-1021-B – 1 kW servo drive (lower power)

• ASD-B2-2023-B – 2 kW servo drive (higher power)

• ASDA-Soft – Configuration and tuning software for Delta servo systems

• ASD-B2-1521-B replacement – Contact PLC ERA for available alternatives
