ASD-BM-50A CN1 50-Pin Terminal Block for ASDA-A2 Servo Drives | Compatible with Delta

The Original New ASD-BM-50A is a 50-pin CN1 breakout terminal block module designed for Delta ASDA-A2 series servo drives. It converts the drive's compact 50-pin SCSI connector into accessible screw terminals, simplifying the wiring of digital, analog, and pulse control signals. This module is essential for system integrators and panel builders who require clean, organized, and reliable connections between the servo drive and PLC or motion controller. The module includes a pre-assembled 50cm cable for direct connection to the drive's CN1 port, and the terminal labels are clearly marked according to the servo drive manual for error-free wiring.

Core Engineering Highlights:
50-pin CN1 breakout terminal block | Screw terminal type | Pre-assembled 50cm cable included | DIN rail or panel mountable | Clear terminal labeling per servo drive manual | Compatible with ASDA-A2 series drives (300W–7.5kW) | Dimensions: 500 × 86.8 × 50.7 mm | Weight: approx. 0.2 kg

Key Features:

• Original New Delta ASD-BM-50A terminal block module

• Converts high-density 50-pin CN1 SCSI connector to standard screw terminals

• Simplifies wiring of digital I/O, analog signals, and pulse inputs/outputs

• Pre-assembled 50cm cable for direct connection to the drive's CN1 port

• DIN rail or panel mounting for easy integration in control cabinets

• Clearly identified terminals per servo drive manual for error-free connection

• Robust screw terminal connections ensure signal integrity and minimize interference

• Facilitates faster troubleshooting and wiring replacement without soldering

• Compact standard DIN profile design

Applications:

• Servo drive wiring in industrial automation systems

• CNC machine tools and motion control panels

• Packaging machinery and material handling equipment

• Robotic systems and multi-axis coordination

• Any application requiring clean CN1 interface wiring for ASDA-A2 drives

Technical Specifications:

System Compatibility:

• Designed for Delta ASDA-A2 series servo drives (300W–7.5kW). Drive model and firmware compatibility should be verified before installation.

• Compatible with ASDA-A, ASDA-A+, ASDA-AB, and ASDA-B series servo drives

• Connects to the CN1 port of the servo drive

• Suitable for use with 230V and 480VAC motor applications

• Compatible motor series: Cx10, Cx13, Ex13, Ex18, Gx13, Fx13, Fx18, Jx10, Jx13, Kx13, Kx18, Lx13, Lx18

Related Products:

• ASD-BM-50A – CN1 terminal block module (current model, obsolete)

• ASD-CNSC0050 – 50-pin SCSI connector for CN1

• ASD-A2 series servo drives – Compatible drive platforms

• Delta ASDA-A2 series servo motors – Compatible motor platforms

PLC ERA is an independent industrial automation distributor supplying genuine Original New products through established global supply channels. All products are factory sealed when applicable and undergo quality inspection prior to shipment. Delta and ASDA-A2 are trademarks of Delta Electronics, Inc.
