DVP04AD-S 4-Channel Analog Input Module 14-Bit DVP-S Series | Delta

The Original New Delta DVP04AD-S is a 4-channel analog input module from the DVP-S Slim Series, designed for high-precision signal acquisition in industrial automation and process control systems. Each channel receives analog voltage or current signals and converts them into 14-bit digital signals. The module connects to Delta DVP-S series PLCs via RS-485 communication and can also be accessed using FROM/TO instructions through the MPU. Its compact DIN-rail-mountable design with pluggable screw terminals simplifies wiring and accelerates installation in space-constrained control cabinets. The DVP04AD-S is suitable for reading signals from temperature, pressure, flow, and level sensors.

⚠️ Important Product Status Note:
This product (DVP04AD-S) has been marked as Obsolete by the manufacturer and is no longer in production. The manufacturer-recommended replacement is the DVP04AD-S2 (enhanced noise immunity version). This product remains a valid spare part for maintaining existing systems. PLC ERA stocks are limited; availability should be confirmed before ordering. For new projects, please consider the recommended replacement model.

Core Engineering Highlights:
4 analog input channels | 14-bit resolution (voltage) / 13-bit resolution (current) | Voltage input range: ±10 V DC (resolution 1.25 mV) | Current input range: ±20 mA (resolution 5 µA) | 14-bit digital conversion for precise signal acquisition | Pluggable screw terminal connections | DIN rail mountable | Built-in RS-485 communication port | 24 V DC / 100–240 V AC power supply | Operating temperature: 0°C to +55°C

Key Features:

• Original New Delta DVP04AD-S module

• 4 analog input channels (voltage or current, configurable per channel)

• Voltage input range: ±10 V DC with 14-bit resolution and 1.25 mV resolution

• Current input range: ±20 mA with 13-bit resolution and 5 µA resolution

• Digital conversion value: ±8,000 for ±10 V input, ±4,000 for ±20 mA input

• Built-in RS-485 communication port for remote access and integration

• Supports communication baud rates: 4,800 / 9,600 / 19,200 / 38,400 bps

• Factory default communication settings: 7,E,1,9600 ASCII, station number 1

• Can be accessed via FROM/TO instructions through the DVP-S series MPU

• Pluggable screw terminal connections for secure field wiring

• DIN rail mounting for space-efficient panel installation

• LED status indicators for module and channel monitoring

• Compact Slim Series form factor for space-constrained installations

• CE and cULus certified

Applications:

• Process variable monitoring (pressure, flow, level, temperature)

• Machine automation and high-precision data acquisition

• Packaging machinery and material handling systems

• Factory automation and process control

• Analog signal conversion for sensors and transmitters

• HVAC systems and building automation

• Temperature, pressure, flow, and level sensing applications

Technical Specifications:

System Compatibility:

• Compatible with Delta DVP-S series PLCs, including DVP-SS2, DVP-SA2, DVP-SX2, DVP-SV2, and DVP-SE series. PLC model and firmware compatibility should be verified before installation.

• Connects to the PLC via RS-485 communication or through the MPU using FROM/TO instructions

• Compatible with Delta DVP-SS2 series PLCs (DVP-14SS11R2 and similar)

• Programmed with Delta WPLSoft or ISPSoft software

• Can be combined with other DVP-S series expansion modules including analog output, temperature, and communication modules

Related Products:

• DVP04AD-S2 – 4-channel analog input module, enhanced noise immunity (recommended replacement)

• DVP06AD-S – 6-channel analog input module, 14-bit resolution

• DVP04DA-S – 4-channel analog output module, 12-bit resolution

• DVP06XA-S – 4 analog inputs + 2 analog outputs, combination module

• DVP04PT-S – 4-channel RTD temperature sensor module (Pt100, Pt1000, Ni100, Ni1000)

• DVP04TC-S – 4-channel thermocouple temperature sensor module (J, K, R, S, T type)

• DVP16SP11T – 8 inputs / 8 transistor outputs digital expansion module

• DVPEN01-SL – Ethernet communication module for DVP-S series

• WPLSoft – Programming software for Delta DVP series

PLC ERA is an independent industrial automation distributor supplying genuine Original New products through established global supply channels. All products are factory sealed when applicable and undergo quality inspection prior to shipment. Delta and DVP are trademarks of Delta Electronics, Inc.
