DVP04PT-S 4-Channel RTD Temperature Module 14-Bit | Delta

The Original New Delta DVP04PT-S is a 4-channel temperature sensor module from the DVP-S Slim Series, designed for high-precision temperature measurement in industrial automation and process control systems. It accepts 2-wire or 3-wire RTD inputs including Pt100, Pt1000, Ni100, Ni1000, LG-Ni1000, Cu100, Cu50, and resistance ranges of 0–300 Ω and 0–3000 Ω. The module converts temperature signals into 14-bit digital signals with 0.1 °C resolution and a conversion time of 200 ms per channel. It connects to Delta DVP-S series PLCs and can share information via RS-485 communication or by direct connection to the DVP-SS main processing unit. Its compact DIN-rail-mountable design with pluggable screw terminals simplifies wiring and accelerates installation in space-constrained control cabinets.

Core Engineering Highlights:
4-channel RTD temperature input | Sensor types: Pt100, Pt1000, Ni100, Ni1000, LG-Ni1000, Cu100, Cu50, 0–300 Ω, 0–3000 Ω | Resolution: 14 bits (0.1 °C) | Conversion time: 200 ms per channel | 2-wire and 3-wire RTD connection | Built-in PID controller function | RS-485 communication port | DIN rail mountable | 24 V DC external power supply | Operating temperature: 0 °C to +55 °C

Key Features:

• Original New Delta DVP04PT-S module

• 4-channel RTD temperature input with 2-wire and 3-wire sensor connection

• Supports Pt100, Pt1000, Ni100, Ni1000, LG-Ni1000, Cu100, Cu50, and 0–300 Ω / 0–3000 Ω resistance inputs

• 14-bit effective resolution with 0.1 °C per LSB engineering unit scaling

• 200 ms conversion time per channel

• Built-in PID controller function for closed-loop temperature regulation

• Direct connection to DVP-SS main processing unit or RS-485 communication

• Pluggable screw terminal connections for secure field wiring

• DIN rail mounting for space-efficient panel installation

• LED status indicators including POWER LED and ERROR LED per channel

• Compact Slim Series form factor for space-constrained installations

• CE and cULus certified

Applications:

• Industrial furnace and oven temperature monitoring

• Injection molding machine temperature control

• Packaging machinery heat sealing and temperature regulation

• Food and beverage processing temperature monitoring

• HVAC systems and building automation

• Plastic and rubber processing equipment

• General process control requiring multi-channel RTD temperature measurement

Technical Specifications:

System Compatibility:

• Compatible with Delta DVP-S series PLCs, including DVP-SS, DVP-SA, DVP-SX, DVP-SV, DVP-EH2, and DVP-EH3 CPU models. PLC model and firmware compatibility should be verified before installation.

• Connects to the PLC via RS-485 communication or through direct connection to the DVP-SS main processing unit

• Compatible with Delta DVP-SS2 series PLCs

• Programmed with Delta WPLSoft or ISPSoft software

• Can be combined with other DVP-S series expansion modules including analog input, analog output, thermocouple, and communication modules

Related Products:

• DVP06PT-S – 6-channel temperature sensor module, RTD inputs (higher density)

• DVP04TC-S – 4-channel temperature sensor module, thermocouple inputs (J, K, R, S, T type)

• DVP04AD-S – 4-channel analog input module, 14-bit resolution (voltage/current)

• DVP04DA-S – 4-channel analog output module, 12-bit resolution

• DVP06XA-S – 4 analog inputs + 2 analog outputs, combination module

• DVP16SP11T – 8 inputs / 8 transistor outputs digital expansion module

• DVPEN01-SL – Ethernet communication module for DVP-S series

• WPLSoft – Programming software for Delta DVP series

• ISPSoft – Advanced programming software for Delta PLC series
