The Original New Delta DVP16SP11R is a 16-point digital I/O extension module for the DVP-S series PLCs, featuring 8 digital inputs and 8 relay outputs. Designed to expand the I/O capacity of Delta Slim Series PLCs, it enables industrial automation systems to control a wider range of devices including solenoids, lamps, contactors, and motor starters. With NPN/PNP selectable input wiring, high-speed response, and a robust relay output design, this module delivers reliable performance for machine control, packaging, and process automation applications.
Core Engineering Highlights:
8 digital inputs @ 24 V DC (NPN/PNP selectable) | 8 relay outputs (SPST-NO) | 1.5 A per point / 5 A per common relay capacity | Response time ≤ 1 ms | Insulation resistance > 5 MΩ at 500 V DC | DIN rail mounting | 0°C to +55°C operating temperature | CE, cULus certified
Key Features:
-
Original New Delta DVP16SP11R module
-
8 digital inputs @ 24 V DC with NPN/PNP selectable wiring
-
8 relay outputs (SPST-NO) for AC/DC load switching
-
Relay output capacity: 1.5 A per point, 5 A per common
-
High-speed response time ≤ 1 ms (typical)
-
Insulation resistance > 5 MΩ at 500 V DC between all I/O points and earth
-
Compact slim form factor for space-efficient panel layouts
-
DIN rail mounting for simple installation
-
Plug-in screw terminal connections for secure field wiring
-
LED indicators for input/output status monitoring
-
Compatible with Delta DVP-S series PLCs (SS/SA/SX/SC/SV)
Applications:
-
Machine automation and control panels
-
Packaging machinery and conveying systems
-
Material handling and logistics equipment
-
Industrial process control
-
OEM equipment requiring digital I/O expansion
-
General factory automation
Technical Specifications:
| Attribute | Specification |
|---|---|
| Catalog Number | DVP16SP11R |
| Product Series | DVP-S Series (Slim Series) |
| Product Type | Digital I/O Extension Module |
| Number of Inputs | 8 digital inputs |
| Input Voltage | 24 V DC |
| Input Type | NPN/PNP selectable (sink/source) |
| Number of Outputs | 8 relay outputs (SPST-NO) |
| Output Type | Relay |
| Rated Output Current | 1.5 A per point / 5 A per common |
| Output Voltage Range | 250 V AC / 30 V DC (max.) |
| Response Time | ≤ 1 ms (typical) |
| Insulation Resistance | > 5 MΩ at 500 V DC (between I/O points and earth) |
| Power Supply Voltage | 24 V DC (-15% ~ +20%) with DC input polarity reverse protection |
| Power Consumption | 2 W (typical) |
| Mounting | DIN Rail |
| Connection Type | Pluggable screw terminal |
| Dimensions (W × H × D) | Approx. 90 × 60 × 40 mm |
| Weight | Approx. 162 g |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | –20°C to +70°C |
| Relative Humidity | 0% to 95% (non-condensing) |
| Certifications | CE, cULus, RoHS |
| Country of Origin | Taiwan |
System Compatibility:
-
Compatible with Delta DVP-S series PLCs including DVP-SS, DVP-SA, DVP-SX, DVP-SC, and DVP-SV
-
Connects to the PLC via high-speed communication bus
-
Compatible with Delta WPLSoft programming software
-
Expandable up to 256 I/O points total (including MPU)
-
Also compatible with other Delta DVP series PLCs supporting Slim Series expansion
Related Products:
-
DVP16SP11T – 8 inputs / 8 sinking transistor outputs (NPN)
-
DVP16SP11TS – 8 inputs / 8 sourcing transistor outputs (PNP)
-
DVP08SP11R – 4 inputs / 4 relay outputs
-
DVP08SN11R – 8 relay outputs
-
DVP08SM11N – 8 digital inputs
-
DVP04AD-S – 4-channel analog input module
-
DVP04DA-S – 4-channel analog output module
-
DVPEN01-SL – Ethernet communication module for DVP-S series
