ECMA-E11315RS 1.5kW AC Servo Motor 2000rpm 20-Bit Encoder | Delta

The Original New Delta ECMA-E11315RS is a 1.5 kW medium-inertia AC servo motor from the ECMA E1 series, designed for precision motion control in industrial automation applications. Rated 1.5 kW (2 HP) at 220 V AC with 2000 rpm rated speed and 7.16 N·m rated torque, this medium-inertia motor delivers stable, reliable performance for loads with significant mass fluctuations. The integrated oil seal protects internal windings and encoder from lubricant and cutting fluid ingress, extending operational life in demanding machining environments. Equipped with a 20-bit incremental encoder (1,280,000 pulses/revolution), keyway shaft with tap, and a 130 mm frame size, the ECMA-E11315RS is suitable for CNC machine tools, industrial robots, packaging machinery, and material handling systems. This model is compatible with Delta ASDA-A2 series servo drives.

Core Engineering Highlights:
1.5 kW (2 HP) rated output | 7.16 N·m rated torque / 21.48 N·m peak torque | 2000 rpm rated speed / 3000 rpm max speed | 20-bit incremental encoder (1,280,000 ppr) | 130 mm frame size | Oil seal and keyway w/ tap | 220 V AC | 8.3 A rated current / 24.9 A max instantaneous current | IP65 protection | 0°C to +40°C operating temperature | CE, cURus certified

Key Features:

• Original New Delta ECMA-E11315RS servo motor

• Medium-inertia rotor design for stable control of high-inertia loads

• 1.5 kW (2 HP) rated output power with 2000 rpm rated speed

• 7.16 N·m rated torque, 21.48 N·m peak torque (3× rated)

• Built-in 20-bit incremental encoder for high-resolution feedback (1,280,000 pulses/revolution)

• Integrated oil seal prevents lubricant and cutting fluid ingress

• Keyway shaft with tap for secure mechanical coupling

• Compact 130 × 130 mm frame size for space-efficient machine integration

• Natural cooling (fanless) for reduced maintenance

• Speed response bandwidth up to 1 kHz

• Compatible with ASDA-A2 series servo drives

• Part Status: Obsolete — no longer manufactured; available as spare part while stocks last

Applications:

• CNC machine tools and milling heads

• Industrial robotic arms and manipulators

• Packaging machinery

• Machine tools and metalworking equipment

• Precision positioning systems

• Automated production lines requiring high-inertia load handling

• Material handling systems

Technical Specifications:

System Compatibility:

• Compatible with Delta ASDA-A2 series servo drives, including ASD-A2-1521-M (1.5 kW, CANopen) and ASD-A2-1521-L (1.5 kW, pulse-train control). Drive model and firmware compatibility should be verified before installation.

• Supports 20-bit incremental encoder configuration

• Compatible with Delta ASDA-Soft configuration software for tuning and setup

• Compatible with Delta DVP, AS, AH series PLCs for motion control integration

• Complete servo system kit available: motor, matched ASDA-A2 drive, encoder cable, and power cable

Related Products:

• ASD-A2-1521-M – 1.5 kW servo drive, CANopen communication (recommended matching drive)

• ASD-A2-1521-L – 1.5 kW servo drive, pulse-train control

• ECMA-E11315SS – Same motor with brake (alternative configuration)

• ECMA-E11320RS – 2 kW medium-inertia servo motor (higher power)

• ECMA-E21315RS – 1.5 kW medium-inertia servo motor (alternate series)

• ASDA-Soft – Configuration and tuning software for Delta servo systems
