ECMA-E21315RS 1.5kW AC Servo Motor 2000rpm 220V | Delta

The Original New Delta ECMA-E21315RS is a 1.5 kW AC synchronous servo motor from the ECMA series, designed for precision motion control in industrial automation applications. Rated 1.5 kW (2 HP) at 220 V AC with 2000 rpm rated speed and 7.16 N·m rated torque, this medium-inertia motor delivers stable performance for loads with significant mass fluctuations. The integrated oil seal protects internal windings and encoder from lubricant and cutting fluid ingress, extending operational life in demanding machining environments. Equipped with a 17-bit incremental encoder, keyway shaft with tap, and 130 mm frame size, the ECMA-E21315RS is suitable for CNC machine tools, industrial robots, packaging machinery, and heavy-duty conveyor systems. This product is compatible with Delta ASDA-B2 series servo drives.

Core Engineering Highlights:
1.5 kW (2 HP) rated output | 7.16 N·m rated torque / 21.48 N·m peak torque | 2000 rpm rated / 3000 rpm max speed | 8.30 Arms continuous output current / 24.90 Arms peak current | 17-bit incremental encoder | 130 mm frame size | Oil seal and keyway w/ tap | 220 VAC (1/3 phase) | 0°C to +40°C operating temperature | CE, cURus certified

Key Features:

• Original New Delta ECMA-E21315RS servo motor

• Medium-inertia design for stable control of high-inertia loads

• 1.5 kW (2 HP) rated output power with 2000 rpm rated speed

• 7.16 N·m rated torque, 21.48 N·m peak torque (approx. 3× rated)

• Built-in 17-bit incremental encoder for high-precision position feedback

• Integrated oil seal prevents gear oil and cutting fluid ingress

• Keyway shaft with tap for secure mechanical coupling

• Compact 130 mm frame size for space-efficient machine integration

• Natural cooling (fanless) for reduced maintenance

• Suitable for high-frequency start-stop cycles without overshoot

• Designed for 1-phase or 3-phase 220 VAC input

• Compatible with ASDA-B2 series servo drives

Applications:

• CNC machine tools and milling heads

• Industrial robotic arms and manipulators

• Heavy-duty conveyor systems

• Packaging machinery

• Machine tools and metalworking equipment

• Precision positioning systems

• Automated production lines requiring high-inertia load handling

Technical Specifications:

System Compatibility:

• Compatible with Delta ASDA-B2 series servo drives (e.g., ASD-B2-1521-B)

• Supports 17-bit and 20-bit encoder configurations with ASDA-B2 drives

• Compatible with Delta ASDA-Soft configuration software for tuning and setup

• Suitable for use with Delta ASDA-A2 series servo drives

Related Products:

• ASD-B2-1521-B – 1.5 kW servo drive for ECMA-E21315RS

• ECMA-C21020RS – 2 kW low-inertia servo motor (higher power)

• ECMA-E21310RS – 1 kW medium-inertia servo motor (lower power)

• ECMA-E21320RS – 2 kW medium-inertia servo motor (higher power)

• ECMA-E21315SS – Same motor with brake (alternative configuration)

• ASDA-Soft – Configuration and tuning software for Delta servo systems
