R1-EC9144D1 4-Channel Analog Output Module EtherCAT 16-Bit | Delta

The Original New Delta R1-EC9144D1 is a 4-channel analog output remote module from the R1-EC series, designed for high-speed, deterministic control in EtherCAT-based machine automation systems. As a fully conformance-tested EtherCAT slave module, it connects seamlessly to any EtherCAT master, enabling precise and synchronized analog signal output to drives, valves, and other field devices. The module provides 4 analog output channels with 16-bit resolution, configurable for voltage or current output modes, making it suitable for demanding real-time applications such as packaging, robotics, CNC machinery, and process control. Its slice-oriented, DIN-rail-mountable design with removable push-and-plug terminals simplifies wiring and accelerates installation, while built-in EMC and vibration resistance ensure reliable operation in harsh industrial environments.

Core Engineering Highlights:
4 analog output channels | 16-bit resolution | Voltage or current output modes | EtherCAT communication protocol | 24 V DC power supply | DIN rail mountable | Removable push-and-plug terminals | EMC immunity per IEC 61131-2 | Vibration resistance per EN 60068-2-6 | Operating temperature: 0°C to +55°C

Key Features:

• Original New Delta R1-EC9144D1 module

• 4 analog output channels, configurable for voltage or current output modes

• 16-bit resolution for precise analog signal generation

• EtherCAT slave module — fully conformance tested through the EtherCAT Technology Group

• Slice-oriented design with removable "push-and-plug" terminals for simplified wiring and quick installation

• DIN rail mountable for space-efficient panel installation

• EMC noise immunity based on ESD, EFT, and RS standards (IEC 61131-2)

• High vibration resistance conforming to EN 60068-2-6 and EN 60068-2-27/29

• LED status indicators for output and module status monitoring

Applications:

• Rubber and plastics machinery

• Laser engraving and flame cutting equipment

• Robotics and five-axis CNC machine tools

• Automatic palletizers and water-jet cutting systems

• Packaging systems

• Production process automation: precise analog control of valves, drives, and actuators

• Energy management: analog signal output for power systems and substations

• Water supply and wastewater treatment

Technical Specifications:

System Compatibility:

• Fully conformance tested EtherCAT slave module, easily connected to any EtherCAT master

• Must be attached to an R1-EC5500 E-bus remote power coupler on the EtherCAT network for remote control

• Compatible with Delta's EtherCAT motion control platform (AX-8 series PC-based controllers)

• Works seamlessly with Delta ASDA-A2-E, ASDA-A3-E, and ASDA-B3-E series servo drives over EtherCAT

• Compatible with Delta MH300 series high-performance compact drives and MS300 series compact drives

• Can be combined with Delta's A2-E Servo Drive and MH300 VFD to create a streamlined, single-source EtherCAT solution

Related Products:

• R1-EC9144D0 – 4-channel analog output module (previous series)

• R1-EC8124D1 – 4-channel analog input module, voltage/current modes, 16-bit

• R1-EC6002D1 – 16-channel digital input module, 0.1 ms response time

• R1-EC6022D1 – 16-channel digital input module, 2 ms response time

• R1-EC7062D1 – 16-channel NPN digital output module, 24 V DC, 1 kHz

• R1-EC5500D0 – EtherCAT gateway/E-bus remote power coupler

• ASD-B3-0721-E – 750 W EtherCAT servo drive (for motion control integration)

• AX-8 Series – PC-based EtherCAT motion controller (for system-level integration)
