VFD037E43A 3.7kW Micro Vector AC Drive 460V 3-Phase | Delta

The Original New Delta VFD037E43A is a 3.7 kW (5 HP) micro vector AC drive from the VFD-E series, designed for reliable motor speed and torque control in industrial automation and OEM machine applications. Rated at 8.5 A continuous output current with a 380–480 V three-phase input, it delivers stable performance for pumps, fans, conveyors, and general-purpose machinery. Featuring sensorless vector control, built-in Modbus RTU communication via RS-485, and a modular design with removable keypad and fan, the VFD-E series offers flexible integration and simplified maintenance. This product has been discontinued by Delta Electronics and is available as a spare part while supplies last. The recommended replacement is the MS-VFD9A0MS43ANSAA from the MS300 series.

Core Engineering Highlights:
3.7 kW (5 HP) rated output | 8.5 A continuous output current (CT) / 10.2 A (VT) | 380–480 V 3-phase input | Sensorless vector control (SVC) + V/F control | 0–600 Hz output frequency | Built-in Modbus RTU (RS-485) | Built-in EMI filter | Modular design with removable keypad and fan | IP20 protection | -10°C to +50°C operating temperature

Key Features:

• Original New Delta VFD037E43A drive

• 3.7 kW (5 HP) rated output power with 8.5 A continuous output current

• 380–480 V AC 3-phase input, 50/60 Hz (±5%, 47–63 Hz)

• Output frequency range: 0–600 Hz

• Sensorless vector control (SVC) and V/F control with 3-point任意 V/F curve

• Built-in Modbus RTU communication protocol via RS-485 (up to 38,400 bps)

• Built-in EMI filter for reduced electromagnetic emissions

• Modular design with easily removable keypad and fan for simplified maintenance

• Supports both induction motors and permanent magnet motors

• Built-in brake chopper (optional external braking resistor)

• Zero-speed holding function for torque maintenance at standstill

• Flexible I/O expansion capability

• DIN rail or chassis mounting

• No keypad included (optional)

Applications:

• Pumps and fans in HVAC and water treatment

• Conveyors and material handling systems

• General-purpose machine control and OEM equipment

• Textile, packaging, and food processing machinery

• Pump and fan applications requiring variable torque control

Technical Specifications:

System Compatibility:

• Compatible with standard 3-phase induction motors up to 3.7 kW

• Supports permanent magnet motors (IPM/SPM) with appropriate parameter settings

• Compatible with Delta PLCs, HMIs, and motion controllers via Modbus RTU (RS-485)

• Supports optional communication modules for extended fieldbus integration

• Suitable for use with Delta braking resistors and AC reactors for harmonic suppression

• Programmed via built-in keypad (optional) or Delta VFDSoft configuration software

Related Products:

• MS-VFD9A0MS43ANSAA – Delta MS300 series 3.7 kW drive (recommended replacement)

• C-VFD037C43A-21 – Delta C2000 series 3.7 kW drive (alternative replacement)

• VFD037E23A – 3.7 kW, 230 V 3-phase version (different voltage class)

• VFD055E43A – 5.5 kW version (higher power)

• VFD022E43A – 2.2 kW version (lower power)

• Braking resistor – External braking resistor for high-inertia loads

• AC Reactor – For harmonic suppression and power quality improvement
