Festo NPFC-E1-2G14-FM 8030299 Threaded Extension G1/4

Festo NPFC-E1-2G14-FM is a straight threaded extension (double nipple) from the NPFC series for pneumatic systems. It extends the distance between two components with G1/4 female threads, provides a simple in‑line solution for extending air line assemblies, and adapts between a G1/4 male and a G1/4 female port. The extension is often used to create space between fittings or to help position an exhaust silencer away from a valve.

Applications:

• Extend spacing between G1/4 pneumatic components

• Raise a fitting above a mounting surface for easier access

• Adapt male G1/4 thread to female G1/4 thread

• Position an exhaust silencer farther from a valve for noise reduction

Core Specifications:

• Part number: 8030299

• Type: Threaded extension (double nipple)

• Connector type: Male‑female

• Thread 1 (male): G1/4

• Thread 2 (female): G1/4

• Material: Brass, nickel‑plated

• Length: 10.5 mm

• Operating pressure range: –0.95 bar … 50 bar

• Ambient / media temperature: –20 °C … +150 °C

• Corrosion resistance class (CRC): 1 – low corrosion stress

• Operating medium: Compressed air to ISO 8573‑1:2010 [‑:‑:‑]

• Packing unit: 10 pieces

• Country of origin: Italy

• RoHS compliant

System Integration:

• Compatible with all Festo G1/4 threaded pneumatic components and standard industrial G1/4 ports.

• The extension can be mounted in any orientation.

• The nickel‑plated brass construction provides good corrosion resistance and durability.

Standards & Compliance:
Refer to manufacturer official documentation for detailed certification and compliance information.

Related Products:

• NPFC‑E1‑2G18‑FM (8030298) – G1/8 threaded version

• NPFC‑E1‑2G38‑FM (8030300) – G3/8 threaded version

• NPFC‑E1‑2G12‑FM (8030301) – G1/2 threaded version
