Mitsubishi GS2110-WTBD-N GS21 GOT Simple Series 10″ Touch Screen HMI

Mitsubishi Electric GS2110-WTBD‑N is a cost‑effective graphic operation terminal (GOT) from the GS21 Simple series, part of the GOT2000 family. Designed for small to medium industrial machine automation and OEM control systems. Provides a 10‑inch widescreen TFT colour display with 800 × 480 WVGA resolution and an analogue resistive touch panel. 15 MB user memory (ROM) and 64 MB operation memory (RAM). Built‑in Ethernet, RS‑232, RS‑422/485, USB device port and SD card slot. Front panel IP65F protection, 24 V DC power supply. Configuration with GT Designer3 (GT Works3) software. This is the current model in the GS21 series, replacing the discontinued GS2110‑WTBD.

Applications:

• Medium‑size machine HMI and operator interface

• Conveyor control and material handling systems

• Packaging machinery and assembly line monitoring

• OEM equipment requiring Ethernet, RS‑232 and RS‑422/485 connectivity

Technical Specifications:

Core Specifications

• Series: GOT2000, GS21 GOT Simple series

• Model: GS2110‑WTBD‑N (black frame)

• Display size: 10.0″ TFT LCD (widescreen)

• Display resolution: 800 × 480 pixels (WVGA)

• Display colours: 65,536 colours (16‑bit)

• Backlight: White LED, 50,000 h typical, non‑replaceable

• Touch panel: Analogue resistive film, minimum 2 × 2 dots detection, 1 million touches min. (operating force ≤ 0.98 N)

• User memory (ROM): 15 MB (Flash memory)

• User memory (RAM): 64 MB

• Power supply: 24 V DC (range 20.4 … 28.8 V DC, ripple ≤ 200 mV)

• Power consumption: 7.6 W max. (approx. 317 mA at 24 V)

• Backlight off power consumption: 3.8 W (158 mA at 24 V)

• Inrush current: 17 A or less (6 ms, 25 °C, max. load)

• Enclosure rating: IP65F (front panel only)

• Mounting: Flush panel mount

• External dimensions (W × H × D): 272 mm × 214 mm × 56 mm

• Panel cut‑out dimensions (W × H): 258 mm × 200 mm

• Weight: approx. 1.3 kg (excluding mounting brackets)

Communication Interfaces

• Ethernet: 1 channel, 100BASE‑TX / 10BASE‑T, RJ45, AUTO MDI/MDI‑X (for controller communication, PC connection, FA transparent function)

• RS‑232: 1 channel, D‑Sub 9‑pin male, speeds 4800‑115200 bps (for controller communication, barcode reader, PC connection)

• RS‑422/485: 1 channel, D‑Sub 9‑pin female, speeds 4800‑115200 bps (for controller communication)

• USB (device): 1 channel (rear face), USB Mini‑B, USB 1.1 Full‑Speed 12 Mbps (for PC connection, FA transparent function)

• SD memory card slot: 1 channel, SDHC compliant (max. 32 GB, for project data read/write, data logging)

Performance Specifications

• Brightness adjustment: 32 levels

• Backlight life: 50,000 h typical

• Touch panel durability: 1 million touches minimum (operating force ≤ 0.98 N)

• Buzzer: Single tone (LONG/SHORT/OFF adjustable)

• Project data write endurance: 100,000 times

Environmental Specifications

• Operating temperature: 0 °C … 50 °C

• Storage temperature: –20 °C … 60 °C

• Operating humidity: 10 % … 90 % RH (non‑condensing)

• Permissible instantaneous power failure: ≤ 5 ms

• Dielectric withstand voltage: 350 V AC for 1 min (across power terminals and earth)

• Insulation resistance: ≥ 10 MΩ at 500 V DC (across power terminals and earth)

• Noise immunity: Conforms to IEC61000‑4‑4, 2 kV (power supply line)

Software Compatibility

• Configuration software: GT Designer3 (GT Works3) version 1.250L or later

System Integration:

• This HMI belongs to the Mitsubishi Electric GOT2000 series, GS21 Simple series.

• Compatible with Mitsubishi Electric PLCs (MELSEC iQ‑R, iQ‑F, Q, L, FX series) and third‑party controllers via Ethernet, RS‑232 or RS‑422/485.

• Supports SDHC memory cards (up to 32 GB) for project data storage, data logging and OS updates.

• Front panel IP65F rating provides dust‑tight and water‑resistant protection for harsh industrial environments.

• The GOT can be started directly from an SD memory card containing the basic OS, communication driver and screen data.

Standards & Compliance:
Refer to manufacturer official documentation for detailed certification and compliance information.

Related Products:

• GS2107‑WTBD‑N – 7″ WVGA version, similar specifications

• GT Works3 – Configuration software for GS21‑N series (version 1.250L or later)

• NZ1MEM‑4GBSD – SDHC memory card for GOT (4 GB)

• GT25‑VNCSKEY‑1 – VNC server function license (supported by GS21‑N models)
