BMXDDO3202K 32-Channel Discrete Output Module 24V DC Positive | Schneider Electric

The Original New Schneider Electric BMXDDO3202K is a 32-channel discrete output module for the Modicon X80 I/O platform, designed to control field devices such as actuators, solenoids, relays, and indicator lights in industrial automation systems. It provides 32 solid-state outputs with positive (source) logic for 24V DC loads at 0.1 A per channel. Part of the common I/O platform for Modicon M340 and M580 Programmable Automation Controllers (PACs), this module reduces maintenance and training costs with compatible modules and unique training for different Programmable Automation Controllers (PACs).

Core Engineering Highlights:
32 solid-state outputs (positive logic/source) | 24V DC (19-30V DC range) | 0.1 A per channel / 3.2 A per module | 1.2 ms response time | 3.6 W power dissipation | 125 mA typical current consumption at 3.3V DC | Reverse polarity, short-circuit, overload, overvoltage protection | IP20 | 0°C to +60°C | 40-way FCN connector | 0.11 kg

Key Features:

• Original New Schneider Electric BMXDDO3202K module

• 32 solid-state discrete output channels with positive (source) logic

• 24V DC rated output voltage (19-30V DC range)

• 0.1 A output current per channel (0.125 A maximum)

• 3.2 A maximum current per module

• 1.2 ms response time for high-speed switching

• <1.5 V maximum voltage drop at state 1

• 0.1 mA maximum leakage current at state 0

• Reverse polarity protection via reverse mounted diode

• Short-circuit protection with 2 A external fuse

• Overload protection with current limiter and electronic circuit breaker (0.125A < Id < 0.185A)

• Overvoltage protection with transil diode

• Outputs can be paralleled (3 maximum) for higher current capability

• Insulation resistance >10 MΩ at 500V DC

• 1.2 W maximum tungsten load

• 290,000 hours MTBF for high reliability

• LED indicators: RUN (green), per channel diagnostic (green), ERR (red), I/O (red)

• 40-way FCN connector for high-density wiring

• IP20 protection for control cabinet environments

• 0°C to +60°C operating temperature

• EAC, Merchant Navy, CSA, RCM, CE, UL certified

• Meets EN/IEC 61131-2, EN 61000-6-4, EN 61000-6-2, EN 61010-2-201 standards

Applications:

• Actuating solenoids, relays, and indicator lights in machine control

• Conveyor and material handling system output expansion

• Packaging machinery and assembly line control

• Factory automation and process control systems

• Medium to large process applications

Technical Specifications:

System Compatibility:

• Schneider Electric Modicon M340 Programmable Automation Controllers (PACs)

• Modicon M580 Programmable Automation Controllers (PACs)

• Modicon X80 I/O backplane and racks

• EcoStruxure Control Expert (formerly Unity Pro) software

• Modicon X80 digital and analog I/O modules

Related Products:

• BMXDDI3202K – 32-channel discrete input module (same series, complementary)

• BMXDDI6402K – 64-channel discrete input module (higher density)

• BMXDDO6402K – 64-channel discrete output module (higher density)

• BMXFTB2000 – 20-way terminal block for field wiring

• BMXFTB4020 – 40-way terminal block for field wiring

• BMXXBP0400 – 4‑slot X80 backplane

• BMXXBP0800 – 8‑slot X80 backplane
