PL40A Rectangular Reflector 40×60 mm Screw Mount | SICK

The Original New SICK PL40A (1012720) is a standard rectangular reflector designed for retro-reflective photoelectric sensors in industrial automation. Its 40 × 60 mm body and 37 × 56 mm reflective area deliver a stable return signal for reliable object detection across a wide range of sensor models. The reflector mounts via screw connection with two holes, allowing precise alignment with the sensor's optical axis. Constructed from PMMA/ABS and rated for operating temperatures from –30 °C to +65 °C, it is suitable for deployment in demanding environments, from cold storage to general factory floors.

Core Engineering Highlights:
37 × 56 mm reflective area | 40 × 60 mm overall body | PMMA/ABS construction | Screw‑on mounting (2 holes) | –30 °C … +65 °C operating temperature | Compatible with a wide range of SICK retro‑reflective photoelectric sensors

Key Features:

• Original New SICK PL40A reflector (part no. 1012720)

• Rectangular shape with a 37 × 56 mm reflective area for precise beam return

• 2‑hole screw mounting for secure installation and fine alignment

• PMMA optical face with ABS housing for durability

• Withstands operating temperatures from –30 °C to +65 °C

• Compact 40 × 60 mm footprint fits space‑constrained installations

• Suitable for standard retro‑reflective sensing applications (for laser‑specific versions, refer to the PL40A Antifog or consult sensor documentation)

Applications:

• Object detection with retro‑reflective photoelectric sensors on conveyor systems

• Packaging machinery for product presence and position verification

• Material handling and logistics sorting lines

• General factory automation and machine control

• Replacement reflector for SICK sensors supplied with PL40A as standard

Technical Specifications:

System Compatibility:

• Compatible with SICK retro‑reflective photoelectric sensors that accept the PL40A reflector. Verify specific sensor‑reflector pairing in the sensor documentation before installation.

• Also compatible with third‑party retro‑reflective sensors that accept standard 40 × 60 mm reflectors.

• Mounts via two pre‑drilled holes using standard screws (mounting hardware not included).

Related Products:

• PL40A Antifog – Anti‑fog variant for high‑humidity or temperature‑gradient environments

• P250 – 47 × 47 mm standard rectangular reflector for alternative mounting

• PL80A – Fine triple reflector, 80 × 80 mm, for longer‑range applications

• PL20A – Compact reflector for space‑constrained installations

• C110A – Standard reflector for short‑to‑medium range sensing
