WL100-2P4439 Retro-Reflective Sensor PNP 7.2m M8 | SICK

The Original New SICK WL100-2P4439 (6052362) is a miniature photoelectric retro-reflective sensor from the W100-2 series, designed for reliable object detection in space-constrained industrial automation. Its dual-lens optical system with minimum distance to the reflector and a visible red LED light source produce a Ø 280 mm light spot at 4 m, enabling precise alignment and stable detection of objects up to a maximum sensing range of 0.01 m to 7.2 m (5.5 m rated with reflector PL80A). Housed in a compact 11 × 31 × 20 mm ABS/PC enclosure rated IP67, the sensor provides a PNP output with selectable light/dark switching and is adjusted via a potentiometer. A P250 reflector and stainless steel mounting bracket (BEF-W100-A) are included in delivery.

Core Engineering Highlights:
Dual-lens retro-reflective sensor | 0.01–7.2 m maximum sensing range / 5.5 m rated | PNP output, light/dark switching selectable | Visible red LED, 632 nm | Ø 280 mm light spot at 4 m | ≤ 0.5 ms response time / 1,000 Hz switching frequency | 10–30 V DC supply voltage | IP67 enclosure rating | M8 4-pin male connector | 11 × 31 × 20 mm miniature housing | –25°C to +55°C operating temperature

Key Features:

• Original New SICK WL100-2P4439 sensor (part no. 6052362)

• Photoelectric retro-reflective sensor with dual-lens system and minimum distance to reflector

• Visible red LED light source (632 nm) for a clearly defined Ø 280 mm light spot at 4 m

• PNP output with selectable light-on/dark-on switching via rotary switch

• Potentiometer for sensitivity adjustment

• Compact rectangular 11 mm width for high-density installations

• ABS/PC plastic housing with PMMA optics and IP67 protection

• M8 4-pin male connector for standard industrial connectivity

• Circuit protection: reverse polarity (A, B) and overcurrent/short-circuit protection (D)

• Supplied with P250 reflector and BEF-W100-A stainless steel mounting bracket

Applications:

• Conveyor object presence and position detection in material handling

• Packaging machinery for container and product verification

• High-speed assembly line part counting and positioning

• Small-part detection in space-constrained machinery

• General factory automation requiring reliable retro-reflective sensing up to 7.2 m

Technical Specifications:

Footnotes:
¹ Reflector PL80A. ² Average service life: 100,000 h at TU = +25°C. ³ Limit values, operation in short-circuit protected network: max. 8 A. ⁴ May not exceed or fall short of UV tolerances. ⁵ Without load. ⁶ Signal transit time with resistive load. ⁷ With light/dark ratio 1:1. ⁸ A = VS connections reverse-polarity protected. ⁹ B = inputs and output reverse-polarity protected. ¹⁰ D = outputs overcurrent and short-circuit protected.

System Compatibility:

• Compatible with standard industrial controllers accepting PNP discrete inputs.

• M8 4-pin male connector mates with standard M8 female cordsets.

• Requires a reflector for operation; P250 included, PL80A recommended for maximum 7.2 m range.

• Configuration is performed via on-device potentiometer and light/dark rotary switch; no software required.

• Mount via through-holes using the supplied BEF-W100-A bracket.

Related Products:

• PL80A – Fine triple reflector for maximum 7.2 m sensing range

• P250 – 47 × 47 mm rectangular reflector (included)

• BEF-W100-A – Stainless steel mounting bracket (included)

• WL100-2P4429 – Same W100-2 series, alternative configuration

• WL100-2N4439 – NPN output variant, same sensing range

• WL100-2P3439 – Same series, alternative configuration

• YF8U14-020VB3XLEAX – M8 straight female cordset, 4-pin, 2 m, PVC
