SICK WL12L-2B530 1018252 Laser Retro‑reflective Photoelectric Sensor 18m

SICK WL12L‑2B530 is a Class 2 laser retro‑reflective photoelectric sensor for non‑contact object detection. Visible red light (650 nm) with Ø 0.8 mm spot at 300 mm. Autocollimation optical system with integrated polarising filter allows operation without a minimum distance to the reflector in demanding industrial applications. Focusable sensing range from 300 mm to infinity. Rugged zinc die‑cast metal housing.

Applications:

• Detecting small objects (e.g., electronic components, miniature parts)

• High‑speed object detection on conveyor and sorting systems

• Material handling and positioning in logistics automation

• Packaging machinery for container and product registration

• Reliable detection of reflective surfaces (metal, shiny plastics)

Core Specifications:

• Sensing range: 0 m … 18 m (with PL80A reflector), focusable from 300 mm to infinite

• Light source: Laser, visible red light, λ = 650 nm, Class 2 (EN 60825‑1)

• Light spot size: Ø 0.8 mm (at 300 mm)

• Supply voltage: 10 … 30 V DC

• Switching output: PNP/NPN (push‑pull), light/dark switching selectable

• Output current: ≤ 100 mA

• Response time: ≤ 200 µs

• Switching frequency: 2,500 Hz

• Sensitivity adjustment: Potentiometer

• Special features: Focusable from 300 mm to infinite

• Degree of protection: IP67, IP69K

• Polarisation filter: yes

• Ambient operating temperature: –10 °C … +50 °C

Advanced Specifications:

• Enclosure rating: IP67 / IP69K (IEC 60529)

• Housing material: zinc die‑cast metal

• Dimensions (W × H × D): 15 mm × 49 mm × 41.5 mm

• Connection type: male connector M12, 5‑pin

• Circuit protection: A (VS reverse‑polarity), C (interference suppression), D (output overcurrent and short‑circuit)

• Protection class: II

System Integration:

• This sensor belongs to SICK W12‑2 Laser series of small photoelectric sensors.

• Requires a separate reflector – PL80A recommended for maximum sensing range (not included).

• Focusable from 300 mm to infinite via mechanical adjustment knob; sensitivity adjustable with potentiometer.

• Mount dimensions match 1‑inch (25.4 mm) hole spacing, compatible with standard SICK brackets.

• M12 5‑pin male connector (pinout details available in product manual) interfaces with industrial control systems.

Standards & Compliance:
Refer to manufacturer official documentation for detailed certification and compliance information.

Related Products:

• PL80A – fine triple reflector for max. 18 m range

• P250 – 47×47 mm rectangular reflector for standard applications

• YF2A14‑xxxVB3XLEAX – M12 straight female connector cable, 5‑pin, various lengths

• BEF‑KH‑W12 – mounting bracket for flexible sensor positioning
