WTB9-3P2261 Photoelectric Proximity Sensor 350mm PNP IP69K | SICK

The Original New SICK WTB9-3P2261 (1049047) is a photoelectric proximity sensor from the W9-3 series, featuring background suppression for reliable, colour-independent object detection in industrial automation. Its compact 12.2 × 49.8 × 23.6 mm rectangular housing is built with SICK's rugged VISTAL® plastic, rated IP66/IP67/IP69K for demanding washdown environments. A PinPoint LED light source (650 nm) produces a precise Ø 4.5 mm light spot at 75 mm, while the 5-turn potentiometer enables accurate sensing range adjustment. The sensor delivers a PNP complementary output (light/dark switching) with a fast 333 µs response time and 1,500 Hz switching frequency, making it suitable for high-speed detection tasks on conveyor systems, packaging lines, and general factory automation. M8 4-pin connector for quick installation.

Core Engineering Highlights:
Background suppression photoelectric proximity sensor | 20 mm … 350 mm maximum sensing range (20–200 mm on low-reflectance targets) | Visible red PinPoint LED, 650 nm | PNP complementary output, light/dark switching | < 333 µs response time / 1,500 Hz switching frequency | 10–30 V DC supply voltage | IP66 / IP67 / IP69K VISTAL® housing | M8 4-pin connector | 12.2 × 49.8 × 23.6 mm | –40°C to +60°C operating temperature

Key Features:

• Original New SICK WTB9-3P2261 sensor (part no. 1049047)

• High-performance background suppression for reliable detection in complex environments

• Wide sensing range up to 350 mm with precise PinPoint LED light

• Rugged VISTAL® housing for high mechanical stability and chemical resistance

• M3 mounting hole for versatile installation

• Comprehensive IP66, IP67, and IP69K protection ratings for harsh conditions

• PNP complementary output with light/dark switching

• 5-turn potentiometer for sensitivity adjustment

• Fast response time < 333 µs and switching frequency up to 1,500 Hz

Applications:

• Object presence and position detection on conveyor systems

• Packaging machinery for product verification and sorting

• Background-independent detection in space-constrained machinery

• High-speed detection tasks in automated assembly lines

• General factory automation and OEM equipment requiring reliable photoelectric sensing

Technical Specifications:

Footnotes:
¹ Object with 90% remission (based on standard white, DIN 5033).
² Object with 6% remission (black).
³ Average service life: 100,000 h at T_a = +25°C.
⁴ Limit values, operation in short-circuit protected network max. 8 A.
⁵ May not exceed or fall short of U_B tolerances.
⁶ Without load.
⁷ Q = light switching.
⁸ At ambient temperature > 50°C, I_max. = 50 mA.
⁹ Signal transit time with resistive load.
¹⁰ With light/dark ratio 1:1.
¹¹ A = U_B connections reverse-polarity protected; B = inputs and output reverse-polarity protected; C = interference pulse suppression.

System Compatibility:

• Compatible with standard industrial controllers accepting PNP complementary outputs.

• M8 4-pin connector mates with standard M8 female cordsets.

• Configuration via on-device 5-turn potentiometer; no software required.

• Mounts via the integrated M3 mounting hole.

Related Products:

• WTB9L-3P2261 (1058230) – Laser version with 25–300 mm sensing range and 0.025 mm minimum resolution

• WTB9-3N2261 – NPN output version of the same sensor family

• WTB9-3P2261S01 – Variant with M12 4-pin connector

• BEF-W9A – Mounting bracket for W9 series sensors

• YF8U14-xxxVB3XLEAX – M8 straight female cordset, 4-pin, various lengths
