6ES7138-6AA01-0BA0 ET 200SP TM Count 1x24V Counter Module 3DI/2DQ | Siemens

The Original New Siemens 6ES7138-6AA01-0BA0 SIMATIC ET 200SP TM Count 1x24V is a high-speed technology module for counting and position detection in distributed I/O systems. It features one 24V counter channel supporting incremental encoders or pulse encoders, plus three additional digital inputs and two transistor outputs for integrated control tasks. Designed for applications requiring precise counting, frequency measurement, and position feedback in compact automation systems.

Core Engineering Highlights:
1x 24V counter channel for incremental/pulse encoders | 200 kHz max input frequency | 800 kHz max counting frequency with quadruple evaluation | 3x additional DI (24V DC, Type 3) | 2x transistor outputs (0.5A per channel) | 24V encoder supply (300 mA, short-circuit protected) | 1W typical power loss | Firmware V2.0 | Firmware upgradeable | Isochronous mode support | I&M0 to I&M3 data | BU type A0 compatible | Colour code CC00 | IP20 protection | –30°C to +60°C operating (horizontal)

Key Features:

• Original New Siemens 6ES7138-6AA01-0BA0 module

• 1x 24V counter channel for incremental encoder (A/B tracks, 90° phase offset, with or without zero track Z) or pulse encoder

• Supports Up/Down counting, frequency measurement, speed measurement, and position detection

• Maximum input frequency: 200 kHz (with shielded cable)

• Maximum counting frequency: 800 kHz with quadruple evaluation

• 3x parameterizable digital inputs (24V DC, Type 3 per IEC 61131) — can be used as gate start/stop, capture, synchronization, or freely usable inputs

• 2x transistor outputs (0.5A per channel, 1A per module max) — short-circuit protected

• 1x 24V encoder supply output — short-circuit protected, max 300 mA

• Counting functions: continuous counting, hardware gate via DI, software gate, event-controlled stop, synchronization via DI, 2 comparators with direction dependency

• I&M data support (I&M0 to I&M3) for identification and maintenance

• Isochronous mode support for synchronized control loops

• Firmware V2.0, upgradeable

• Configurable input delays: 0.05, 0.1, 0.4, 0.8, 1.6, 3.2, 12.8, 20 ms

• Fast input response: min 6 µs (with "none" parameterization)

• Status and diagnostics LEDs: PWR, DIAG, channel status, forward counting, backward counting

• Suitable for BU type A0 base units

• Colour code CC00 for visual identification

• 15 mm width for high-density mounting

• DIN rail mounting, IP20 protection

• Reverse polarity protection

• Mechanical coding element Type B

• Cable length: shielded up to 1000 m, unshielded up to 600 m

• Engineering via TIA Portal V15 SP1 or higher / STEP 7 V5.6 or higher

• Active product lifecycle

Applications:

• High-speed counting and quantity measurement on production lines

• Position detection with 24V incremental encoders

• Frequency, speed, and period measurement

• Conveyor belt speed monitoring and material tracking

• Length measurement for cutting and packaging applications

• Position feedback for S7-1500 Motion Control technology objects

• Pulse width measurement and event counting

• OEM equipment requiring high-speed counter functionality

Technical Specifications:

• Catalog Number: 6ES7138-6AA01-0BA0

• Product Type Designation: TM Count 1x24V

• Product Family: SIMATIC ET 200SP

• Firmware Version: V2.0 (upgradeable)

• HW Functional Status: From FS03

• Usable Base Units: BU type A0

• Colour Code: CC00

Encoder Input (Counter Channel):

Digital Inputs:

Digital Outputs:

Encoder Supply:

Power Supply & Current:

Address Area:

Physical & Environmental:

Engineering & Configuration:

System Compatibility:

• Siemens SIMATIC ET 200SP distributed I/O system

• ET 200SP interface modules (IM155-6PN, IM155-6MF, etc.)

• SIMATIC S7-1500 controllers (including Motion Control technology objects)

• SIMATIC S7-1200, S7-300, S7-400 controllers

• TIA Portal engineering framework (V15 SP1 or higher)

• STEP 7 V5.6 or higher

• PROFINET and PROFIBUS networks

• BU type A0 base units

Typical System Architecture:
ET 200SP Interface Module (e.g., IM155-6PN)
↓
6ES7138-6AA01-0BA0 TM Count 1x24V Module (15 mm width)
│
├── 1x Counter Channel → 24V Incremental Encoder (A/B/Z) / Pulse Encoder
│ ├── Max 200 kHz input frequency (800 kHz with 4× evaluation)
│ └── Up/Down counting, frequency measurement, position detection
├── 3x Digital Inputs (24V) → Gate start/stop / Capture / Synchronization
├── 2x Transistor Outputs (0.5A) → Comparator outputs / Alarm signals
├── 1x 24V Encoder Supply (300 mA) → Sensor power
│
↓
PROFINET Network → SIMATIC Controller (S7-1500 / S7-1200)

Related Products:

• 6ES7138-6AA01-0BA0 – TM Count 1x24V (current model)

• 6ES7138-6BA01-0BA0 – TM PosInput 1 (SSI absolute encoder module)

• 6ES7193-6BP00-0BA0 – BaseUnit BU15-P16+A0+2B (BU type A0)

• 6ES7193-6BP20-0BA0 – BaseUnit BU15-P16+A10+2B (BU type A0 with AUX terminals)

• 6ES7193-6PA00-0AA0 – Server module for ET 200SP

PLC ERA is an independent industrial automation distributor supplying 100% genuine Original New products through established global supply channels. Siemens, SIMATIC, ET 200SP, and TIA Portal are trademarks of Siemens AG.
